如下為我司愛澤工業IZE_Industries本月到貨J+J相關產品，歡迎致電索取樣本資料和產品信息。

J+J執行器J4C-S20

J+J執行器J4C-S55

J+J執行器J4-S20

J+J執行器J4C-S35

J+J執行器J4C系列介紹

J4C 執行器主要用于自動化 1/4 轉 (90°) 閥門。

多電壓

該系統可控制輸入電流，并在必要時將其轉換為 24 VDC，這是所有 J4C 系列執行器電機的供電電壓。

分體式 PCB

輕松更換 PCB。所有型號通用。

無刷發動機

用戶可以享受減少維護、提高效率、降低發熱和噪音的優勢。

可視化操作控制

常亮的外部 LED 指示燈指示執行器正常運行。不同的 LED 指示燈閃爍顏色頻率指示執行器的狀態。

電子扭矩限制器

為防止損壞設備或閥門，執行器配備電子扭矩控制系統，當檢測到電機功耗超過允許值時，該系統會停止執行器的運行。

系統停止執行器并釋放齒輪上的壓力，以便啟動緊急手動控制 (MO)。同時，外部 LED 會發出彩色閃爍頻率，指示執行器因扭矩過大而停止。

可分離手動緊急控制

將控制桿置于“手動”位置可自動斷開電氣系統與齒輪系的連接，閥門可手動操作。如果執行此操作后，控制桿未返回“自動”位置，并且未發出打開或關閉閥門的操控信號，則執行器將不會移動，LED 會頻繁閃爍，指示執行器處于手動位置。

或低時間電壓

占空比 (DUTY) 是指開始新操控之前的總操控時間，即運動時間加上執行器必須停止的時間。通常以百分比 (%) 為單位。了解操控的總時間對于計算閥門的開啟和關閉過程非常重要。示例：占空比 75%

輔助微動開關

執行器配備 4 個微動開關：2 個用于停止電機，2 個無源輔助開關用于傳輸打開或關閉位置信號（開-關）。

溫度控制

3.5W 恒溫控制加熱器自動將內部溫度保持在 20°C (68°F) 以上，以防止冷凝損壞。操作結束后，切勿斷開電源，否則將斷開 ATC。

The J4C actuator is designed to automate mainly 1/4 turn (90o) valves

MULTI-VOLTAGE

This system controls and transforms the input current, if necessary, to 24 VDC, which is the voltage at which all J4C series actuator motors are powered.

SPLIT PCB

Easy PCB replacement. Common in all models.

ENGINE BRUSHLESS

Users can take advantage of reduced maintenance, improved efficiency, and reduced heat and noise.

VISUAL OPERATION CONTROL

Constantly illuminated external LED indicates normal operation of the actuator. There are different LED flash color frequencies that indicate the status of the actuator.

ELECTRONIC TORQUE LIMITER

To prevent damage to the unit or valve, the actuators have an electronic torque control system that stops the operation of the actuator when it detects a motor power consumption greater than permitted.

The system stops the actuator and releases pressure on the gears to facilitate activation of the emergency manual control (MO) and, at the same time, the external LED emits a frequency of colored flashes, indicating that the actuator has stopped due to excessive of torque.

DECLUTCHABLE MANUAL EMERGENCY CONTROL

Placing the lever in MANUAL automatically disconnects the electrical system from the gear train and the valve can be operated manually. If after doing this, the lever is not returned to the AUTO position and a maneuver signal is sent to open or close the valve, the actuator will not move and the LED will flash frequently indicating that the actuator is in manual position .

OR LOW TIME VOLTAGE

The DUTY is the total maneuver time before starting the new maneuver, that is, the time in motion plus the time the actuator must be stopped. It is generally measured in %. It is important to know the total time of the maneuver to calculate the valve opening and closing process. Examples: Duty 75%

AUXILIARY MICRO SWITCHES

The actuator is equipped with 4 microswitches: 2 for stopping the motor and 2 voltage-free auxiliary switches for transmitting the open or closed position signal (on-off).

TEMPERATURE CONTROL

A thermostatically controlled 3.5W heater automatically maintains the interior temperature above 68°F (20°C) to prevent damage from condensation. Never disconnect the power at the end of the maneuver as we will disconnect the ATC.

J+J執行器J4M系列介紹

J4M執行器專為多回轉閥門設計。

多電壓

該系統可控制輸入電流，并在必要時將其轉換為 24 VDC，這是所有 J4M 系列執行器電機的供電電壓。

分離式 PCB

易于更換 PCB。所有型號均采用此設計。

藍牙

他們?cè)趫?zhí)行器中集成了藍牙通信系統，使其能夠通過任何安卓設備與執行器進行通信。用戶可以通過手機或平板電腦控制執行器的開啟、關閉或停止，并接收有關錯誤或事件等的信息。

無刷發動機

用戶可以享受到減少維護、提高效率、降低發熱和噪音的優勢。

數字位置系統

模擬輸入被發送到 CPU 進行處理，并與執行器的位置進行持續比較，從而獲得靈敏度以及位置重復性（參見特性）。 DPS 與執行器電子系統通信，提供對執行器運動的全面管理。

可視化操作控制

外部 LED 常亮指示執行器正常運行。LED 閃爍顏色頻率不同，指示執行器的狀態。

可拆卸手動應急控制裝置

將控制桿置于“手動”位置可自動斷開電氣系統與齒輪系的連接，閥門可手動操作。如果執行此操作后，控制桿未返回“自動”位置，且未發送打開或關閉閥門的操控信號，則執行器將不會移動，LED 指示燈將頻繁閃爍，指示執行器處于手動位置。

或低時間電壓

DUTY 是指開始新操控之前的總操控時間，即運動時間加上執行器必須停止的時間。通常以百分比表示。了解操控的總時間對于計算閥門的開啟和關閉過程非常重要。示例：占空比 75%

溫度控制

3.5W 恒溫控制加熱器自動將內部溫度保持在 20°C (68°F) 以上，以防止冷凝損壞。操作結束后切勿斷開電源，否則將斷開 ATC 連接。

The J4M actuator is designed for multi-turn valves

MULTI-VOLTAGE

This system controls and transforms the input current, if necessary, to 24 VDC, which is the voltage at which all J4M series actuator motors are powered.

Split PCB

Easy PCB replacement. Common in all models.

BLUETOOTH

They has incorporated theBLUETOOTHcommunication system into the actuators, allowing them to communicate with them from anyANDROIDdevice. From their mobile phone or tablet, they can command the actuator to open, close, or stop, and also receive information about errors or incidents, etc.

ENGINE BRUSHLESS

Users can take advantage of reduced maintenance, improved efficiency, and reduced heat and noise.

POSITION SYSTEM DIGITAL

The analog inputs are sent to the CPU where they are processed for continuous comparison with the position of the actuator, this allows obtaining a very high sensitivity along with a very high repeatability of the position (see characteristics). The DPS in communication with the actuator electronic system provides comprehensive management of the actuator movement.

Visual control of operation

Constantly illuminated external LED indicates normal operation of the actuator. There are different LED flash color frequencies that indicate the status of the actuator.

Detachable manual emergency control

Placing the lever in MANUAL automatically disconnects the electrical system from the gear train and the valve can be operated manually. If after doing this, the lever is not returned to the AUTO position and a maneuver signal is sent to open or close the valve, the actuator will not move and the LED will flash frequently indicating that the actuator is in manual position .

Or Low Time Voltage

The DUTY is the total maneuver time before starting the new maneuver, that is, the time in motion plus the time the actuator must be stopped. It is generally measured in %. It is important to know the total time of the maneuver to calculate the valve opening and closing process. Examples: Duty 75%

Temperature control

A thermostatically controlled 3.5W heater automatically maintains the interior temperature above 68°F (20°C) to prevent damage from condensation. Never disconnect the power at the end of the maneuver as we will disconnect the ATC.

J+J執行器常用型號：

J+J J4C-S20

J+J J4C-S35

J+J J4C-S55

J+J J4C-S85

J+J J4C-B20

J+J J4C-B35

J+J J4C-B55

J+J J4C-B85

J+J J4C-S140

J+J J4C-S300

J+J J4C-B140

J+J J4M-S2

J+J J4M-B2

J+J J4M-S6

J+J J4M-B6

J+J J4M-S10

J+J J4M-B10

J+J J4M-S25

J+J J4M-B25

J+J J4M-S40

J+J J4M-B40

J+J J10H

如果您需要完整的J+J的相關技術咨詢，請隨時致電愛澤工業，或者訪問網站，我們將盡全力解決您的問題。

If you have any question for J+J，Please feel free to communicate with us and we will do our best to solve your problem.
